4” Touchscreen Display 480×320 Raspberry Pi

Availablity:

In stock


Compare

شاشة لمس خاصة بالرازبيري باي بحجم 4 انج، مع قلم لمس.

38,250 IQD

In stock

4” Touchscreen Display 480×320 Raspberry Pi 3 model B/2B/B+/A+/B

Features:
– Designed for Raspberry Pi, easy to use
– Supports any revision of Raspberry Pi (directly-pluggable)
– Driver provided (works with custom Raspbian directly)
– Supports Raspbian system, enables your system to:
– Play videos (supports multi formats, MP4 and so on)
– Take photos by touching (up to 17 camera modes)
– Support software keyboard (system interaction without keyboard/mouse)
– High quality immersion gold surface plating

Package Includes:
1 x Raspberry Pi 4inch IPS LCD
1 x Touch Pen

Key Parameters

LCD Type TFT
LCD Interface SPI
Touch Screen Type Resistive
Touch Screen Controller XPT2046
Colors 65536
Backlight LED
Resolution 480*320 (Pixel)
Aspect Ratio 4:3
SPI Diver Speed 16Mhz
Backlight Current TBD
Operating Temp TBD



Interface

PIN NO. SYMBOL DESCRIPTION
1, 17 3.3V Power positive (3.3V power input)
2, 4 5V Power positive (5V power input)
3, 5, 7, 8, 10, 12, 13, 15, 16 NC NC
6, 9, 14, 20, 25 GND Ground
11 TP_IRQ Touch Panel interrupt, low level while the Touch Panel detects touching
18 LCD_RS Instruction/Data Register selection
19 LCD_SI / TP_SI SPI data input of LCD/Touch Panel
21 TP_SO SPI data output of Touch Panel
22 RST Reset
23 LCD_SCK / TP_SCK SPI clock of LCD/Touch Panel
24 LCD_CS LCD chip selection, low active
26 TP_CS Touch Panel chip selection, low active



SKU: 350-LCD4IN Categories: ,
  • Designed for Raspberry Pi, easy to use
  • Supports any revision of Raspberry Pi (directly-pluggable)
  • Driver provided (works with custom Raspbian directly)
  • Supports Raspbian system, enables your system to:
  • Play videos (supports multi formats, MP4 and so on)
  • Take photos by touching (up to 17 camera modes)
  • Support software keyboard (system interaction without keyboard/mouse)
  • High quality immersion gold surface plating
