ATmega 328P IC
In stock
متحكم Atmega 328-P المستعمل في بوردات الاردوينو اونو. يمكن استعماله مباشرة وبرمجته عن طريق الكومبيوتر.
4,500 IQD
In stock
ATmega328 is a single-chip microcontroller created by Atmel in the megaAVR family.
The Atmel 8-bit AVR RISC-based microcontroller combines 32 kB ISP flash memory with read-while-write capabilities, 1 kB EEPROM, 2 kB SRAM, 23 general purpose I/O lines, 32 general purpose working registers, three flexible timer/counters with compare modes, internal and external interrupts, serial programmable USART, a byte-oriented 2-wire serial interface, SPI serial port, 6-channel 10-bit A/D converter, programmable watchdog timer with internal oscillator, and five software selectable power saving modes. The device operates between 1.8-5.5 volts. The device achieves throughput approaching 1 MIPS per MHz
If you want to Burning the Bootloader Click Here for tutorial.
| Voltage |
|---|
| Parameter | Value |
|---|---|
| CPU type | 8-bit AVR |
| Performance | 20 MIPS at 20 MHz |
| Flash memory | 32 kB |
| SRAM | 2 kB |
| EEPROM | 1 kB |
| Pin count | 28-pin PDIP |
| Maximum operating frequency | 20 MHz |
| Number of touch channels | 16 |
| Hardware QTouch Acquisition | No |
| Maximum I/O pins | 26 |
| External interrupts | 24 |
| USB Interface | No |
| USB Speed | No |
