Bluetooth HC-06 Slave Module

Allows your device to both send and receive the TTL data via Bluetooth technology without connecting a serial cable to your computer.

Feature:
– Works with any USB Bluetooth adapters.
– Default Baud Rate: 9600, 8, 1, n.
– Built in antenna.
– Coverage up to 30ft.
– Bluetooth version: V2.0+EDR
– Input voltage: 3.3~6V
– Operating voltage: 3.3V
– Signal coverage: 30ft
– Size: 4.3 x 1.6 x 0.7cm
– Weight: 3g
– Commercial Series: Bluetooth module board Series
– With LED indicator light, use 150mA and 3.3V regulation chip.
– With VCC.GND.TXD.RXD foot for the Bluetooth
– Compatible with Bluetooth master module. Slave module or master-slave (whole) module.

Notes:
– Input power supply 3.3~6V, Prohibit more than 6V
– No “Automatically prevent power supply function, so please correctly connect power supply.
– We advise to install “Bluetooth master module”
– The “State” is output foot for LED status, when Bluetooth “Unconnected”, output “Pulse”; when Bluetooth “connected”, output “High level”, we can determine the states from “MCU”

Package Includes:
1 x HC-06 Bluetooth module

SKU: 256-HC06 Category:
  • Works with any USB Bluetooth adapters.
  • Default Baud Rate: 9600, 8, 1, n.
  • Built in antenna.
  • Coverage up to 30ft.
  • Bluetooth version: V2.0+EDR
  • Input voltage: 3.3~6V
  • Operating voltage: 3.3V
  • Signal coverage: 30ft
  • Size: 4.3 x 1.6 x 0.7cm
  • Weight: 3g
  • Commercial Series: Bluetooth module board Series
  • With LED indicator light, use 150mA and 3.3V regulation chip.
  • With VCC.GND.TXD.RXD foot for the Bluetooth
  • Compatible with Bluetooth master module. Slave module or master-slave (whole) module.
